LPC4320FET100
€4.60
The LPC4320FET100 is an Arm Cortex-M4 based digital signal controller with an Arm Cortex-M0 coprocessor designed for embedded applications requiring signal processing. The Arm Cortex-M4 core offers single-cycle Multiply-Accumulate and SIMD instructions and a hardware floating-point unit to support signal processing while the M0 coprocessor handles I/O and digital control processing. The LPC4320FET100 includes 200 kB of data memory, one High Speed USB 2.0 Host/OTG/Device, advanced configurable peripherals such as the State Configurable Timer (SCT), Serial General Purpose I/O (SGPIO), and SPI Flash Interface (SPIFI) as well as an external memory controller and multiple digital and analog peripherals.
Description
Features
High Performance 32-bit Microcontroller (MCU) based on Arm® Cortex®-M4/M0 Cores
- All information for LPC4320FET100
Package
TFBGA100: plastic thin fine-pitch ball grid array package; 100 balls; body 9 x 9 x 0.7 mm
Buy Options
LPC4320FET100,551
12NC: 935294171551
Details
Order
Order from distributors
Order from distributors
Operating Features
| Parameter | Value |
|---|---|
|
Operating Frequency [Max] (MHz)
|
204
|
|
GPIO
|
49
|
|
USB Controllers
|
1
|
|
USB (speed)
|
HS
|
|
USB (type)
|
host/device
|
|
CAN
|
2
|
|
UART
|
4
|
|
I2C
|
2
|
| Parameter | Value |
|---|---|
|
SPI
|
3
|
|
ADC (Channels)
|
2
|
|
ADC (bits)
|
10
|
|
ADC sample rate
|
400 ksps
|
|
SCTimer / PWM
|
1
|
|
Supply Voltage [min] (V)
|
2.2
|
|
Supply Voltage [max] (V)
|
3.6
|
|
Product category
|
190-LPC4300-
|
Environmental
| Part/12NC | PbFree | EU RoHS | Halogen Free | RHF Indicator | REACH SVHC | Weight (mg) |
|---|---|---|---|---|---|---|
|
LPC4320FET100,551(935294171551)
|
Yes
|
Yes
Certificate Of Analysis (CoA) |
Yes
|
 |
REACH SVHC |
166.54298921
|
Quality
| Part/12NC | Safe Assure Functional Safety | Moisture Sensitivity Level (MSL) | Peak Package Body Temperature (PPT) (C°) | ||
|---|---|---|---|---|---|
| Lead Free Soldering | Lead Soldering | Lead Free Soldering | |||
|
LPC4320FET100,551
(935294171551) |
No
|
3
|
240
|
260
|
|
Shipping
| Part/12NC | Harmonized Tariff (US)Disclaimer | Export Control Classification Number (US) |
|---|---|---|
|
LPC4320FET100,551
(935294171551) |
854231
|
3A991A2
|
Product Change Notice
| Part/12NC | Issue Date | Effective Date | PCN | Title |
|---|---|---|---|---|
|
LPC4320FET100,551
(935294171551) |
2018-03-17 | 2018-06-25 | 201801009F01 | LPC18xx LPC43xx BGA Package Cu Wire Qualification for NXP-ATKH |
